醫療級平板電腦 · 第 11 代
OmniMPC-241
醫療級平板電腦 · 24 吋醫療級平板電腦 第 11 代平台
OmniMPC-241，茂鑫智能科技 24吋醫療級 Panel PC，Intel® 第11代 Tiger Lake，無風扇 43mm 超薄設計，IP65 防護，IEC 60601-1 認證。
- Intel® 第 11 代 Core™ i5-1135G7
- 23.8" FHD VA · 3000:1 · P-Cap 觸控
- 無風扇 43mm · IP65 · IEC 60601-1
產品特色
IP65 防護 · 醫療認證
正面 IP65 防水防塵，符合 IEC 60601-1 醫療電氣設備標準，適用高潔淨度環境
無風扇 44mm 薄型
完全無風扇被動散熱設計，機身僅 44mm 厚，零噪音，適合長時間連續運作
遠距醫療支援
整合 5MP 攝影機、雙麥克風陣列與揚聲器，一機完整支援視訊診療場景
觸控鎖定 · 備用電池
觸控鎖定防止清潔誤觸；可選配熱插拔備用電池，確保不間斷醫療服務
24" Full HD 觸控
23.8" 1920×1080 VA 面板，10 點電容式多點觸控，300 nits 高亮度顯示
Intel® 第 11 代效能
搭載 Tiger Lake UP3 平台，最高可配 Core™ i5，處理複雜醫療影像與多工應用
多 I/O · 雙網路
4× USB 3.0、4× USB 2.0、2× GbE LAN、HDMI、COM、音源孔、Wi-Fi 6 / Bluetooth 5.2
OEM / ODM 客製
支援外觀、功能、I/O 接口全面客製化，提供從設計到量產的完整解決方案
產品規格
核心元件
| Platform | Intel® Core™ i Series 11th Gen Tiger Lake |
|---|---|
| Model | Core™ i5-1135G7 |
| Integrated Graphics | Intel® Iris® Xe Graphics |
| Security | fTPM (Default) | dTPM (Optional) |
| Memory Type | 2× DDR4 SO-DIMM (Dual Channel) |
|---|---|
| Capacity Options | 4GB / 8GB / 16GB / 32GB |
| Primary (M.2) | 1× M.2 M-Key 2280 : 64GB – 1TB SSD / SATA |
| Secondary (SATA) | 1× 2.5" SATA Drive Bay (SSD / HDD) |
| Expansion Slots | 1× M.2 M-Key 2230 PCIe (Wi-Fi) | 1× Mini PCIe + USB 2.0 |
顯示器
| Size | 23.8" Full HD |
|---|---|
| Resolution | 1920 × 1080 px |
| Panel Type | VA (Wide Viewing Angle) |
| Brightness | 250 nits |
| Contrast Ratio | 3000:1 |
| Viewing Angle | 178° (H) × 178° (V) |
| Colors | 16.7M |
| Touch Technology | Projected Capacitive (P-Cap) Multi-Touch |
|---|---|
| Touch Points | 10-Point Simultaneous Touch |
| Touch Lock | Supported (prevents accidental input during cleaning) |
| Glove Operation | Supports Medical Glove Touch |
I/O 介面
| USB 3.0 | × 4 (Type-A) |
|---|---|
| USB 2.0 | × 4 (Type-A) |
| LAN | 2× RJ45 GbE LAN |
| Display Output | HDMI × 1 |
| Serial Port | 1× COM |
|---|---|
| Audio Out | 1× 3.5mm Audio Jack For Speaker Box (Option) |
| Power Connector | DC Jack 19V |
| Control Keys | Vol ▲▼ · Brightness ▲▼ · Touch Lock |
| VESA Mounting | 75×75mm / 100×100mm |
無線 & 多媒體
| Wi-Fi | 802.11 a/b/g/n/ac |
|---|---|
| Bluetooth | 5.2 |
| Camera | 5MP Full HD Front Camera (with Privacy Shutter) |
|---|---|
| Microphone | Dual Microphone Array (Noise Cancelling) |
| Speakers | 2 × 3W Built-in Speakers |
| Telemedicine | Video Consultation Integration Supported (HIPAA Compatible) |
| RFID | Optional HF 13.56MHz or LF 125KHz |
機構 & 環境
| Dimensions | 581 × 351 × 43mm (W × H × D) |
|---|---|
| Weight | 7.8 KG (without battery) |
| Cooling | Fanless Passive Cooling |
| Chassis Material | Medical White Die-Cast Aluminum |
| IP Rating | IP65 (Front Panel) |
| AC Input | 100–240V, 50/60Hz |
|---|---|
| DC Input | 19V DC (4.74A) |
| Backup Battery | 10.8V / 9220mAh, Removable / Hot-Swap |
| Operating System | Windows 11 64-bit |
| Operating Temp. | 0°C – 35°C (32°F – 95°F) |
| Storage Temp. | -20°C – 60°C (-4°F – 140°F) |
| Humidity | 20% – 80% (Non-Condensing) |
認證 & 客製
| Medical Electrical | IEC 60601-1 |
|---|---|
| Safety Standard | IEC 62368-1 |
| EMC | FCC Class B |
| Security | fTPM (Default) | dTPM (Optional) |
| Antimicrobial | Antimicrobial Housing |
| Customization | OEM / ODM |
